Great Basin™ Indoor/Outdoor
Polyethylene Grease Interceptors
Schier Model Specifications and Technical Documents
G
P
M
Capacity Outside
Dimensions (in)
Pipe Size
Plain End
Weight
in
Specification Submittal Revit Installation & Operation
and Maintenance Guides
Grease Solids Liquid
lbs
Gallons
Gallons
L
W
H
(option)
lbs
PDF
DWG
PDF
DWG
RFA
PDF
 GB-15 15 74 3.9 16 25 19 14¼ 2 (3) 26
 GB-20 20 109 6.4 22 27 21 15 2 (3) 31
 GB-25 25 75 6.4 22 27 21 15 3 (2) 31
 GB-35* 35 142 9.5 35 33 25 25 3 (2,4) 77
 GB-50 50 249 12.5 52 37 28 28½ 4 (3) 92
 GB-75 75 616 19.2 125 46 32 38½ 4 (6) 130
 GB-250** 100 1,076 105 275 68 33½ 51½ 4 (6) 230
* If GB-35 is ordered with 4" connections, subtract 1" from adaptor/riser height range.
** For flow rates above 100 GPM & grease capacities above 1076 lbs., see "Application Specific Details" link above for series & parallel configurations.
